가스 희석장치

정밀 가스 희석기 GDS-100

제품 특징

  • Photo cell (O3 Generator module) (Range 0 – 0.1 to 0- 1 ppm)
  • 7 inch TFT LCD touch screen interface
  • Ethernet, RS-232, RS-485 & USB ports
  • Temperature & pressure compensation
  • Stored data can be retrieved RS-232, USB Interface and TCP/IP network

상세규격

Flow Range of Dilution Air 0 – 10 SLPM
Flow Range of Cylinder Gases ±1% of full scale
Flow Measurement Accuracy ±1% of full scale
Repeatability of Flow Control ±0.5% of full scale
Linearity of Flow Measurements ±0.5% of full scale
Cylinder Gas Input Port 3
Diluent Air Input Port 1
Gas out Port 1
Display 7 inch Graphic LCD
Operating Temperature 0 – 40°C
Power Requirement 220 VAC / 60 Hz or 230 VAC / 50 Hz
